- Hardness: 10-500 N, Resolution: 0.01 N, Accuracy: 0.1 N
- Diameter: 2-25 mm, Resolution: 0.01 mm, Accuracy: 0.1 mm
- Thickness: 0.5-15 mm, Resolution: 0.01 mm, Accuracy: 0.1 mm
- Weight: 1-20,000 mg, Resolution: 1 mg, Accuracy: 20 mg
Tablet Hardness Tester, THDT-5E
Descrição
The Intelligent Tablet Hardness Tester is a 4-in-1 pharmaceutical testing and analytical instrument designed for measuring the physical parameters of tablets, including weight, hardness, diameter, and thickness. It is widely used in pharmaceutical factories, drug inspection institutes, and relevant research institutions.
Features
- The user interface is controlled by a microcontroller, making it convenient and quick to use.
- Equipped with high-precision pressure sensors to ensure high measurement accuracy.
- Features an LCD display with English interface.
- Automatically performs statistical analysis, printing, and display of measurement data.
- Features a real-time calendar and clock function, allowing testing and calibration dates and times to be printed on the test report.
- Includes a self-diagnosis function to automatically prompt the user in case of anomalies during testing.
- Built-in thermal printer, with an optional external dot matrix printer available.
- Features a calibration function with a convenient and simple calibration process.
Specifications
| Model | THDT-5E |
| Measurement Range | Hardness: 10-500 N, Resolution: 0.01 N, Accuracy: 0.1 N |
| Diameter: 2-25 mm, Resolution: 0.01 mm, Accuracy: 0.1 mm | |
| Thickness: 0.5-15 mm, Resolution: 0.01 mm, Accuracy: 0.1 mm | |
| Weight: 1-20,000 mg, Resolution: 1 mg, Accuracy: 20 mg | |
| Measurement Units | Hardness: N / kg / kPa (Selectable) |
| Diameter: mm / inch (Selectable) | |
| Measurement Mode | Manual single-tablet / Automatic continuous (max. 100 tablets per run) / Selectable |
| Display | 7-inch touch screen |
| Printer Interface | Centronic standard serial printer interface, connectable to micro-printers (English output) |
| Power Supply | 220V/50Hz |
